WP30ID
FSH
| Model | WP20ID | WP30ID | WP40ID |
| Type | casting iron pump | ||
| suction*delivery(mm) | 50*50 | 80*80 | 100*80 |
| Impeller diameter(mm) | 175 | 188 | 150 |
| Max Lift head(m) | 65 | 85 | 60 |
| Suction head(m) | 7 | 8 | 8 |
| Max delivery volume(m³/h) | 30 | 42 | 90 |
| mechanical seal | Ceramic carbon | ||
| Diesel Engine model | FSH178F 7.0HP Diesel | FSH186F 10HP Diesel | FSH192F 13HP Diesel |
| Packing size(L*W*H)mm | 560*470*575 | 560*470*575 | 650*490*615 |
| Net weight(KG) | 53 | 55 | 62 |
