gx100
honda
GX100 | |
|---|---|
| Engine Type | Air-cooled 4-stroke OHC |
| Bore x Stroke | 56 X 40 mm |
| Displacement | 98.5 cm3 |
| Net Power Output* | 2.8 hp (2.1 kW) @ 3,600 rpm |
| Net Torque | 4.2 lb-ft (5.7 Nm) @ 3,600 rpm |
| PTO Shaft Rotation | Counterclockwise (from PTO shaft side) |
| Compression Ratio | 8.5:1 |
| Carburetor | Float Type |
| Ignition System | Transistorized magneto |
| Starting System | Recoil |
| Lubrication System | Splash |
| Governor System | Centrifugal Mechanical |
| Air Cleaner | Dual element |
| Oil Capacity | 0.42 US qt (0.40l) |
| Fuel Tank Capacity | .81 U.S. qt (.77 liter) |
| Fuel | Unleaded 86 octane or higher |
| Dry Weight | 23.4 lb (10.6 kg) |
GX100 | |
|---|---|
| Engine Type | Air-cooled 4-stroke OHC |
| Bore x Stroke | 56 X 40 mm |
| Displacement | 98.5 cm3 |
| Net Power Output* | 2.8 hp (2.1 kW) @ 3,600 rpm |
| Net Torque | 4.2 lb-ft (5.7 Nm) @ 3,600 rpm |
| PTO Shaft Rotation | Counterclockwise (from PTO shaft side) |
| Compression Ratio | 8.5:1 |
| Carburetor | Float Type |
| Ignition System | Transistorized magneto |
| Starting System | Recoil |
| Lubrication System | Splash |
| Governor System | Centrifugal Mechanical |
| Air Cleaner | Dual element |
| Oil Capacity | 0.42 US qt (0.40l) |
| Fuel Tank Capacity | .81 U.S. qt (.77 liter) |
| Fuel | Unleaded 86 octane or higher |
| Dry Weight | 23.4 lb (10.6 kg) |
