GX270
HONDA
Honda Gx270 Gasoline Engine Gx160 Gx390 is supplied by Yancheng Fujiheng Power Machinery Co., Ltd. for engine matching and machinery power supply. The information below helps buyers understand typical applications, selection points, service capability and quotation requirements without relying on keyword stuffing.
Before ordering, please confirm the working environment, expected capacity, matching engine or power requirement, quantity and destination market. Fujiheng Power can help recommend a suitable model and provide quotation details based on your application.
Q: Can this product be supplied for OEM or batch orders?
A: Please contact Fujiheng Power with your required specification and quantity. We can discuss model matching, packaging and delivery requirements.
Q: What information is needed for a quotation?
A: Product model, application, quantity, destination, preferred configuration and any special technical requirements are helpful for accurate quotation.
| Model | GX160 | GX200 | GX270 | GX390 |
| Engine Type | Air-cooled 4-stroke OHV | Air-cooled 4-stroke OHV | Air-cooled 4-stroke OHV | Air-cooled 4-stroke OHV |
| Bore x Stroke | 68 X 45 mm | 68 X 54 mm | 77 X 58 mm | 88 X 64 mm |
| Displacement | 163 cm3 | 196 cm3 | 270 cm3 | 389 cm3 |
| Net Power Output* | 4.8 HP (3.6 kW) @ 3,600 rpm | 5.5 HP (4.1 kW) @ 3,600 rpm | 8.5 HP (6.3 kW) @ 3,600 rpm | 11.7 HP (8.7 kW) @ 3,600 rpm |
| Net Torque | 7.6 lb-ft (10.3 Nm) @ 2,500 rpm | 9.1 lb-ft (12.4 Nm) @ 2,500 rpm | 14.1 lb-ft (19.1 Nm) @ 2,500 rpm | 19.5 lb-ft (26.4 Nm) @ 2,500 rpm |
| PTO Shaft Rotation | Counterclockwise (from PTO shaft side) | Counterclockwise (from PTO shaft side) | Counterclockwise (from PTO shaft side) | Counterclockwise (from PTO shaft side) |
| Compression Ratio | 9.0 : 1 | 8.5:1 | 8.5:1 | 8.2:1 |
| Lamp/Charge coil options | 25W, 50W / 1A, 3A, 7A | 25W, 50W / 1A, 3A, 7A | 25W, 50W / 1A, 3A, 10A, 18A | 25W, 50W / 1A, 3A, 10A, 18A |
| Carburetor | Butterfly | Butterfly | Butterfly Float Type | Butterfly Float Type |
| Ignition System | Transistorized magneto | Transistorized magneto | Digital CDI with variable timing | Digital CDI with variable timing |
| Starting System | Recoil Starter | Recoil Starter | Recoil/electric | Recoil/electric |
| Lubrication System | Splash | Splash | Splash | Splash |
| Governor System | Centrifugal Mechanical | Mechanical | Centrifugal Mass Type | Centrifugal Mass Type |
| Air cleaner | Dual Element | Dual element | Dual element | Dual element |
| Oil Capacity | 0.61 US qt. (0.58 L) | 0.63 US qt (0.6l) | 1.16 US qt (1.1 L) | 1.16 US qt (1.1 L) |
| Fuel Tank Capacity | 3.3 U.S. qts (3.1 liters) | 3.3 U.S. qts (3.1 liters) | 5.6 U.S. qts (5.3 liters) | 6.4 U.S. qts (6.1 liters) |
| Fuel | Unleaded 86 octane or higher | Unleaded 86 octane or higher | Unleaded 86 octane or higher | Unleaded 86 octane or higher |
| Dry Weight | 33 lbs. (15.1 kg) | 35 lbs. (16.1 kg) | 55 lb (25 kg) | 69 lb (31.5 kg) |
