English
 |
■ Long life- 60% longer life
■ “ EASY START” switch
■ Low fuel consumption
■ No fuel residual
| Quantity: | |
|---|---|
FSH6500
FSH
| Gasoline generator set | |||||||
| model | FSH2000 | FSH2500 | FSH3500 | FSH6500 | FSH7500 | FSH8500 | FSH10000 |
| type | brush,single-phase | ||||||
| voltage regulate | AVR | ||||||
| frequency(Hz) | 50/60 | ||||||
| rated AC voltage(V) | 110/120/220/230/240 | ||||||
| rated AC output KW | 1.5/1.8 | 2.0/2.2 | 2.5/3.0 | 5.0/5.5 | 6.0/6.5 | 7.0/7.5 | 7.0/8.0 |
| MAX AC output KW | 1.7/2.0 | 2.2/2.5 | 2.8/3.5 | 5.5/6.5 | 6.5/7.0 | 7.5/8.0 | 8.0/8.5 |
| power factor | 1 | 1 | 1 | 1 | 1 | 1 | 1 |
| engine model | FSH160 | FSH200 | FSH200 | FSH390 | FSH420 | FSH440 | FSH460 |
| engine type | OHV 4--STROKE,FORCED AIR-COOLED | ||||||
| fule tank capacity ( L) | 15 | ||||||
| ignition system | T.C.L | ||||||
| starting system | recoil/electric start | ||||||
| packing size(L*W*H)mm | 610*535*470 | 610*535*470 | 610*535*470 | 700*605*600 | 700*605*600 | 700*605*600 | 700*605*600 |
| Net weight (KG) | 40 | 42 | 51 | 85 | 96 | 105 | 110 |
| 20/40FT UNIT | 225/475 | 225/475 | 225/475 | 128/272 | 128/272 | 128/272 | 128/272 |
| Gasoline generator set | |||||||
| model | FSH2000 | FSH2500 | FSH3500 | FSH6500 | FSH7500 | FSH8500 | FSH10000 |
| type | brush,single-phase | ||||||
| voltage regulate | AVR | ||||||
| frequency(Hz) | 50/60 | ||||||
| rated AC voltage(V) | 110/120/220/230/240 | ||||||
| rated AC output KW | 1.5/1.8 | 2.0/2.2 | 2.5/3.0 | 5.0/5.5 | 6.0/6.5 | 7.0/7.5 | 7.0/8.0 |
| MAX AC output KW | 1.7/2.0 | 2.2/2.5 | 2.8/3.5 | 5.5/6.5 | 6.5/7.0 | 7.5/8.0 | 8.0/8.5 |
| power factor | 1 | 1 | 1 | 1 | 1 | 1 | 1 |
| engine model | FSH160 | FSH200 | FSH200 | FSH390 | FSH420 | FSH440 | FSH460 |
| engine type | OHV 4--STROKE,FORCED AIR-COOLED | ||||||
| fule tank capacity ( L) | 15 | ||||||
| ignition system | T.C.L | ||||||
| starting system | recoil/electric start | ||||||
| packing size(L*W*H)mm | 610*535*470 | 610*535*470 | 610*535*470 | 700*605*600 | 700*605*600 | 700*605*600 | 700*605*600 |
| Net weight (KG) | 40 | 42 | 51 | 85 | 96 | 105 | 110 |
| 20/40FT UNIT | 225/475 | 225/475 | 225/475 | 128/272 | 128/272 | 128/272 | 128/272 |
